Features

• IP65 dust and waterproof
• Impact shock detection (ISD) providing feedback to prevent damage to the weight sensor
• Flow rate display (FRD) that makes calculating and recording flow rates easier and more accurate
• Shock logging function that records up to 50 adverse impact loads with a timestamp for later inspection
• Cushioning under the weighing pan to mitigate impact shocks significantly
• Flow rate comparator that indicates whether the flow rate is within the designated limits
• Tare memory function that saves the tare value in non-volatile memory
• Automatic self calibration in response to temperature changes or according to set schedules (GX-M)
• Automatic minimum weight calculation with either ECL or an actual, external weight
• Alert function to ensure that the measured quantity is not smaller than the set minimum weight
• Selectable response characteristics for trading weighing speed for higher display stability or vice versa
• User access control (UAC) that password-protects the balance from misuse
• GLP/GMP/GCP/ISO compliant output to meet documentation requirements
• Universal Flexi Coms (UFC) to customize printout content and layout
• Gross/Net/Tare output
• Data memory function to save weighing results, calibration results, unit masses to be used in counting mode, etc., in the device itself
• Counting mode with the Automatic Counting Accuracy Improvement (ACAI) function
• Percent mode function for target weighing or checking sample variation
• Animal weighing (average & hold) function for weighing moving objects
• Statistical calculation function (SCF) to facilitate the analysis of measurements
• Five-level comparator function with buzzer
• Auto power ON and OFF functions
• Density determination function
• Underhook for weighing a magnetic material as well as measuring density

External Input/Output

• RS-232C interface (standard)
• Quick/bi-directional USB interface*4 (standard)
• Comparator relay output/buzzer/external key input interface (optional)
• Analog output interface (optional)

Options

• GXM-04 : Comparator relay output/buzzer/RS-232C/external key input interface
• GXM-06 : Analog (0-1/0.2-1 V) output/RS-232C interface
• GXM-08 : Ethernet (TCP/IP) interface
• GXK-012: Animal weighing pan
• GXK-015: Carrying case
• GXM-27 : Bluetooth® interface
• Only one of GXM-04, GXM-06, GXM-08, GXM-27, or the standard (RS-232C and USB) interfaces can be used.
• The GX-M/GF-M series are not IP65 with GXM-04, GXM-06 or GXM-08
• Analog output is updated according to the display refresh rate. Display refresh rate can be changed in the internal settings of the balance. (approx. 5/10/20 times/sec)
