Features

• Flexible display position with either swing-arm or separate display stand
• IP65 dust and waterproof
• Impact shock detection (ISD) providing feedback to prevent damage to the weight sensor*1
• Shock logging function that records up to 50 adverse impact loads with a timestamp for later inspection
• Flow rate display (FRD) that makes calculating and recording flow rates easier and more accurate*2
• Flow rate comparator that indicates whether the flow rate is within the designated limits
• Automatic level detection and warning
• Tare memory function that saves the tare value in non-volatile memory
• AD-Just – Automatic self-sensitivity adjustment according to the set execution condition using the internal weight (GX-L)
• Automatic precision assessment (APA) using the electronically controlled load (ECL)
• Automatic minimum weight calculation with either ECL or an actual, external weight
• Alert function to ensure that the measured quantity is not smaller than the set minimum weight
• Selectable response characteristics for trading faster weighing speed for higher display stability or vice versa
• User access control (UAC) that password-protects the balance from misuse
• GLP/GMP/GCP/ISO compliant output to meet documentation requirements
• Universal Flexi Coms (UFC) to customize printout content and layout *3
• Gross/Net/Tare output
• Data memory function to save weighing results, sensitivity
• adjustment/calibration test results, unit masses to be used in counting mode, etc., in the device itself
• Counting mode with the Automatic Counting Accuracy Improvement (ACAI) function
• Percent mode function for target weighing or checking sample variation
• Animal weighing (average & hold) function for weighing moving objects
• Statistical calculation function (SCF) to facilitate the analysis of measurements
• Five-level comparator function with buzzer
• Auto power ON and OFF functions
• Density determination function
• Underhook for weighing a magnetic material as well as measuring density (optional)

External Input/Output

• RS-232C interface (standard)
• Quick/bi-directional USB interface*⁴ (standard)
• Comparator relay output/buzzer/external key input interface (optional)
• Analog (0-1/0.2-1 V) output interface (optional)

*4 Users can toggle between the Quick USB mode (plug-and-play with weighing data output to a PC only) and the Virtual COM mode (for bi-directional communication) with internal settings. For the latter, a special driver (available for download here) needs to be installed on the PC (except for those with Windows 10/11).

Options

• GXL-04*⁵*⁶ : Comparator relay output/buzzer/RS-232C/external key input interface    Manual (PDF 1.8 MB)
• GXL-06*⁵*⁶ : Analog (0-1/0.2-1 V) output/RS-232C interface    Manual (PDF 1.8 MB)
• GXL-07 : 5-meter cable for the GX-LS
• GXL-08*⁵*⁶ : Ethernet (TCP/IP) interface    Manual (PDF 545 KB)
• GXL-27*⁵*⁷ : Bluetooth® interfacee    Manual (PDF 447 KB)
• GP-12 : Animal weighing pan    Manual (PDF 111 KB)
• GP-16 : AD-8127 printer support    Manual (PDF 167 KB)
• GP-20 : Underhook for models with 42 kg capacity or below    Manual (PDF 636 KB)
• GP-21 : Underhook for models with 62 kg capacity or above    Manual (PDF 636 KB)

  *5 Only one of GXL-04, GXL-06, GXL-08, GXL-27, or the standard (RS-232C and USB) interfaces can be used. *6 The GX-L/GF-L series are not IP65 with GXL-04, GXL-06 or GXL-08. *7 Please contact your local A&D representative to find out whether GXL-27 is certified for compliance with Bluetooth® communication laws in your country.
