A&D Borealis BA-T/BA Series

Premium-Level Micro/Semi-Micro Balances

Sophisticated Weighing at a Touch

Come experience premium weighing solutions with outstanding ease of use and maintenance. In addition to promising fully reliable results, A&D Borealis BA-T/BA series provides exceptional efficiency and time savings to improve your daily tasks and routines while meeting various laboratory requirements. An ideal choice if you seek superior professional quality and need nothing but the best!

 Brochure BA-T Manual BA Manual

Categories: , ,

Features

  • Automatic opening/closing of the breeze break doors using non-contact IR sensors
  • 5-inch wide color touch screen that enables intuitive operation (for the BA-T series)
  • External ionizer for instant static removal*1
  • Detachable breeze break unit and easily separable glass panes for better cleanability*2
  • No grooves for the sliding doors so that contaminants do not accumulate
  • Inner breeze break for 0.001 mg models to increase stability*2
  • On-screen leveling assist (for the BA-T series)
  • Impact shock detection (ISD) providing feedback to prevent damage to the weight sensor (patented)
  • AD-Just – Automatic self sensitivity adjustment using the internal weight
  • Internal repeatability test to quickly assess the performance under a given environment
  • Daily/periodic balance check support (for the BA-T series)
  • Smart routine check (SRC) function (for the BA-T series)
  • Minimum weight setting and alert functions
  • User access control (UAC) with user rights management and password lock functions
  • History information for log-in/log-out, operation, sensitivity adjustment, and impact shock detection (ISD) (for the BA-T series)
  • Data memory function (for the BA series)
  • Selectable response characteristics for trading faster weighing speed for higher display stability or vice versa
  • GLP/GMP/GCP/ISO compliant output to meet documentation requirements
  • Universal Flexi Coms (UFC) to customize printout content and layout*3
  • Gross/Net/Tare output
  • Formulation mode for quick, accurate weighing of multiple samples to mix (for the BA-T series)
  • HPLC mode for preparing buffer solutions for high-performance liquid chromatography (for the BA-T series)
  • Counting mode with the Automatic Counting Accuracy Improvement (ACAI) function
  • Percent mode function for target weighing or checking sample variation
  • Statistical calculation function (SCF) to facilitate the analysis of measurements (for the BA-T series)
  • Auto power ON and OFF functions
  • Underhook for weighing a magnetic material as well as measuring density
*1 Optional for the BA-225/225D/125D *2 Patent pending

Accessories

  • RS-232C interface
  • Quick/bi-directional USB interface*6
  • External key input (jack socket) × 2
  • USB host interface (for the BA-T series)
  • Ethernet (TCP/IP) interface (for the BA-T series)
  • Bluetooth® interface (for the BA-T series)
*6 Users can toggle between the Quick USB mode (plug-and-play with weighing data output to a PC only) and the Virtual COM mode (for bi-directional communication) using internal settings. For the latter, a driver (available for download here) needs to be installed on the PC (except for those with Windows 10).

Specifications

Model BA-6TE BA-6E BA-6DTE BA-6DE BA-225TE BA-225 BA-225DTE BA-225D BA-125DTE BA-125D
Capacity 6.2 g 2.1 g / 6.2 g*i 220 g 51 g / 220 g*i 51 g / 120 g*i
Readability 0.001 mg 0.001 mg / 0.01 mg 0.01 mg 0.01 mg / 0.1 mg 0.01 mg / 0.1 mg
Repeatability (standard deviation)*ii 0.0010 mg (for 1 g) 0.0030 mg (for 6 g) 0.0025 mg (for 1 g) 0.01 mg (for 6 g) 0.015 mg (for 50 g) 0.03 mg (for 200 g) 0.025 mg (for 50 g) 0.1 mg (for 200 g) 0.030 mg (for 50 g) 0.1 mg (for 200 g)
Minimum weight*iii (typical) 1.8 mg 4.0 mg 20 mg 32 mg 50 mg
Linearity ±0.010 mg ±0.010 mg / ±0.02 mg ±0.15 mg ±0.2 mg ±0.2 mg
Stabilization time (typical when set to FAST) Approx. 10 secs Approx. 10 secs / 10 secs Approx. 7 secs Approx. 7 secs / 3 secs Approx. 7 secs / 3 secs
Weighing pan Ø25 mm Ø85 mm
