Product

LC-4103

Single Point Aluminum Load Cells

For Use with Medium Size Platforms, Single Point Compact Load Cells


Capacity	Model No.
60 kgf	LC4103-K060
100 kgf	LC4103-K100
150 kgf	LC4103-K150

Category: Load Cell

Features

Features

Parallelogram-type construction
400 × 600 mm platforms can be used
Temperature compensation maintains both zero and span from -10 °C to +40 °C (+14 °F to +104 °F)
Deadweight up to 80% of capacity. Load weight and deadweight up to 180% of capacity
Moisture proof
Compact and lightweight
