Specifications
| Rated capacities (Emax) | 10t | 20t | 30t | 50t |
| Sensitivity | 2.0±0.002mV/V | 2.0±0.002mV/V | 2.0±0.002mV/V | 2.0±0.002mV/V |
| Accuracy class | C2~C5 | C2~C5 | C2~C5 | C2~C5 |
| Zero balance | ±1% F.S | ±1% F.S | ±1% F.S | ±1% F.S |
| TCO | ±0.02% F.S/10° | ±0.02% F.S/10° | ±0.02% F.S/10° | ±0.02% F.S/10° |
| TC SPAN | ±0.02% F.S/10° | ±0.02% F.S/10° | ±0.02% F.S/10° | ±0.02% F.S/10° |
| Input impedance | 400±20Ω | 400±20? | 400±20? | 400±20? |
| Output Impedance | 352±5Ω(L≥15m) | 352±5Ω(L≥15m) | 352±5Ω(L≥15m) | 352±5Ω(L≥15m) |
| Insulation impedance | ≥5000MΩ | ≥5000MΩ | ≥5000MΩ | ≥5000MΩ |
| Temperature range, compensated | -10°C~±40°C | -10°C~±40°C | -10°C~±40°C | -10°C~±40°C |
| Temperature range, operating | -30°C~+70°C | -30°C~+70°C | -30°C~+70°C | -30°C~+70°C |
| Maximum safe overload | 150% F.S | 150% F.S | 150% F.S | 150% F.S |
| Ultimate overload | 250% F.S | 250% F.S | 250% F.S | 250% F.S |
| Excitation, recommend | 10~12V DC | 10~12V DC | 10~12V DC | 10~12V DC |
| Excitation, maximum | 15V DC | 15V DC | 15V DC | 15V DC |
| Protection class | IP68 | IP68 | IP68 | IP68 |
| Construction | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
| Cable Length | 8m | 8m | 14m | 16m |
