AD-4404

Check Weighing Indicator

More Choices from New Advanced Weighing indicator for Numerous



  • 100 times/sec. High speed sampling.
  • High display resolution to 16,000 counts.
  • Up to 1 million counts of A/D resolution.
  • Easy to get judgment by Hi/OK/Lo or HiHi/Hi/Lo/LoLo comparator lights with buzzer.
  • Foreign material detection input is newly added.

Brochure | Manual Book

Category:

Features

  • 100 times/sec. High speed sampling.
  • High display resolution to 16,000 counts.
  • Up to 1 million counts of A/D resolution.
  • Easy to get judgment by Hi/OK/Lo or HiHi/Hi/Lo/LoLo comparator lights with buzzer.
  • Foreign material detection input is newly added.
  • Bar graph shows where the weight of an object falls within the OK range.
  • Built-in timer controls weighing process by signal from an external photoelectric switch or by programmable weight recognition function that is beneficial for transparent objects.
  • Weight, accepted piece, accumulated piece count, name of the object weighted, and standard deviation can be displayed at the touch of button.
  • Up to 100 sets of target (OK weight), Hi, Lo and tare can be stored by individual code number.
  • 5 digits of target and 4 digits of upper and lower limit can be set by the front key operation and number of digit and its location can be customized.
  • Bright and large 13mm (0.52 inch) florescent display.
  • 1/16000 display resolution capability precise enough for any application.
  • Sealed keys keep out dust in industrial environments.
  • 100 times/second fast sampling.
  • Standard current loop output and standard RS-485.
  • Full digital calibration makes zero and span calibration a breeze.
  • Complete RFI/EMI protection.
  • Many features simplify operation.
  • Display (default) – Stores and recalls up to 100 sets of pre-sets items by individual code number.
    • Total number of pieces checked
    • Total number of pieces accepted
    • Target weight
  • Bar graph indicates deviation from target weight Heavy-duty construction
  • Easy installation
  • Simple calibration
  • 11 inputs and 11 open collector output standard (Optional dry contact relay)
  • Auto zero maintenance with adjustable parameters
  • Comparator buzzer
  • Front panel key lock out prevents operator tampering
  • Fully selectable decimal joint positioning
  • Programmable gravity compensation
  • Selectable units of measuring: None, g, kg, t, lbs (USA)


Options

  • OP-01 : BCD output
  • OP-02 : Relay output
  • OP-03 : RS-422/RS-485 I/O
  • OP-04 : RS-232C I/O
  • OP-05 : Parallel I/O
  • OP-07 : Analog output
